Hobbywing Xrotor 10A Mini 3S ESC For Multi-Rotor System (1PCS)

  • $7.58


Features:

  • Special core program for multi-rotor controllers greatly improves throttle response.
  • Specially optimized software for excellent compatibility with disc-type motors.
  • All settings except the "Timing" are preset, making usage simple, highly intelligent and adaptive.
  • The twisted-pair design of the throttle signal cable effectively reduces the crosstalk produced in signal transmission and makes flight more stable.
  • Compatible with various flight-control systems and supports a signal frequency of up to 621Hz (Note: all throttle signals over 500Hz are non-standard signals).
  • Special drive chip has much better MOSFET driving effect than common driving circuit consisted of discrete components.
  • MOSFET with extra-low resistance brings high performance and great current endurance.

Specs:

  • Con. Current: 10A
  • Peak Current: 15A
  • BEC: No
  • LiPo: 2-3S
  • Programmable Item: Timing (High/Intermediate)
  • Weight: 7g
  • Size: 44.2x12.2x9.2 mm
  • Typical application: 250 Class Quadcopter
